FINGER PRINT ICLOCK700
iClock700 is a 3.5-inch TFT screen Time Attendance & Access Control Terminal. Adopting the new user-friendly firmware, iClock700 has new features like stunning GUI, more stability, faster matching speed and better expandability.
iClock700 is compatible with various types of USB flash disks, ADMS and former SDK. Moreover, RS232/485, TCP/IP, and USB host/client ensures a smooth date transmission between device and PC. It also has GPRS, WIFI and 3G connectivity and access control connectivity with Wiegant out and in, electric lock, door sensor, exit button, alarm and Door Bell.
Features
• Remarkable User Experience
• Intuitive and stunning UI designed with the most
popular and internationalized element.
• Interface operation adopts modularized hierarchical
design. Simpler, Better and More logical.
• Faster matching speed: Less than 0.5 second.
• Enhanced Features and Performance
• Multi-languages
• Data backup and retrieve.• Advanced User ID consisted of
letters and numbers.
• Chip encryption for firmware protection.
• Excellent Expandability
• Easy to extend functions and customize
customers’requirements.
• Access Control Interface
• For Wiegand in and out, door lock
connection, alarm and bell. -
ICLOCK 260 BIOMETRIC TIME & ATTENDANCE
ICLOCK 260 BIOMETRIC TIME & ATTENDANCE
Specification:
- User capacity : 1500
- Transaction capacity : 30000
- Linux Operating System
- Verification mode : 1:1 or 1:N
- Fingerprint identification speed – 3,500 match in 1 second
- False Rejection Rates (FRR): <=1%
- False Acceptance Rate (FAR): <=0.0001%
- Identification speed: <=2 seconds
- Allowable finger Rotation +/- 180 degrees
- Algorithm Version Bio9.0
- Communication: TCP/IP, USB
- USB Standalone operation (flash disk required)
- Display: TFT 65,000 Real colour
- Keyboard: 8 Function Numeric
- Power: 12 VDC, standby current: 50MA, work current: 400 MA
- End/Start Bell operation
- Temperature operating: 0’C – 45’C
- Humidity operating: 20%-80%
- Size: 160(W)*140(L)*45(H)mm
- Software: ZK Time
-
iClock 360
iClock360 is an innovative biometric fingerprint reader for Time & Attendance applications, offering unparalleled performance using an advanced algorithm for reliability, precision and excellent matching speed. The iClock360 features the fastest commercial-based fingerprint matching algorithm and ZK high-performance, high-image quality optical fingerprint sensor. The 3.5” TFT can display more information vividly, including user photo, fingerprint image quality and verification result etc. 8 function keys are the shortcuts to change the attendance status, work-code or to browse the short message, and can be defined as required. TCP/IP communication is standard and make sure the data transmission between terminal and PC can be easily done within several seconds.
Fingerprint Capacity 8000 Card Capacity 10,000 (Optional) Record Capacity 200,000 Display 3.5-inch Screen Communication TCP/IP, RS232, USB host/client (optional) Standard Functions Workcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, T9 input, and photo-ID , 9 digit user ID Optional Functions ID/Mifare/HID, Webserver and Wi-Fi, ADMS, External Bell and Printer Software ZKTime.Net 3.0, BioTime 8.0 Power Supply DC 12V 1.5A Verification Speed ≤ 1 sec Operating Temp. 0°C- 45°C Operating Humidity 20%-80% Dimension 192×140×41mm (Length×Width×Thickness) Gross Weight 1.05 kg -
iClock 880
iClock880 time attendance and access control terminal adopts ZKSoftware latest ZEM600 platform with ZKFinger 10.0 fingerprint algorithm to improve identification speed. It can manage 10000 templates within 1.5 second (I: N identification). iClock880 features ZK’s high performance, high image quality optical fingerprint sensor. The patented optical sensor is resistant to scratches, impact, vibration and electrostatic Shock.
Because of the common development platform, existing customer will be able to use iClock880 and co-exist with any existing ZK readers without re-enrolling the users. The iClock880 can be used in multi factor authentication that supports fingerprint, password, Proximity and Smart card. It also has an option for Wi-Fi and GPRS connectivity.iClock880 has camera and 3.5” color TFT-LCD display, so it can display the individual graphical interfaces and personnel color photos. It comes standard with TCP/IP, RS-232/485, USB-host, USB-client, 8 functions keys, T9 input method, backup battery and has access control connectivity for Wigand-in, Wigand-out, Door lock connection, Alarm, Bell, Remote to Exit switch.
System Type: Biometric System Segment: Office Transactions: 800000 Display Size: 3.5 Connectivity: USB Identification Speed: 0 Color: Black Dimensions(WxDxH)mm: 213x475x178 Warranty: 1 Biometric Type: Fingerprint Features: 000 templates, 50, 8 user-defined function keys, Audible and Visual indications, Internal Camera, Multi-language support, Optional integrated proximity, Relay contacts, smart card reader, Standard backup battery Display: LCD Lock Type: 0 Body Material: 0 Fire Resistant: 0 Frequency: 0 -
iFace 302
iFace302 multi-biometric identification time attendance and access control terminal adopts ZKSoftware’s latest ZEM600 platform with ZK Face 7.0 algorithm and large capacity memory. iFace series integrated 630MHz high speed ZK Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of iFace are designed to be performed on the 4.3 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional WiFi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure.
Display 4.3’’ TFT Touch Screen
Face capacity 1200 (1:N)
Fingerprint capacity 2000
ID Card capacity 10,000
Logs capacity 100,000
Algorithm Version ZKFaceVX 7.0 & ZKFinger VX10.0
2000mAh backup battery Optional
Communication TCP/IP, RS232/485
USB-HOST Two USB-Host
Wireless Wi-Fi Optional
Time attendance Standard functions Automatic Status Switch, Self-Service Query,
Work Code, T9 input, 9 digit user ID, DST, Photo-ID, Scheduled-bell
Access control interfaces for 3rd Party Electric Lock, Door Sensor, Exit Button
Wiegand Signal Output
Optional functions ID/Mifare Card, Extendable, GPRS, Wi-Fi, 3G, AMDS
Power supply DC12V 3A
Verification Speed ≤2 sec
Operating temp 0 °C- 45 °C
Operating Humidity 20%-80%
Dimension(W×H×D) 193.6×146.8×111 mm
Gross Weight 1.49 kg -
iFace 402
iFace402 multi-biometric identification time attendance and access control terminal adopts ZKSoftware’s latest ZEM600 platform with ZK Face 7.0 algorithm and large capacity memory. iFace series integrated 630MHz high speed ZK Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of iFace are designed to be performed on the 4.3 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional WiFi or GPRS. Optional built-in 2000 mAh battery eliminates the trouble of power-failure.
Display 4.3’’ TFT touch screenFace 1200 (1:N)
Face capacity 1200 (1:N)
Fingerprint capacity 2000
ID Card capacity 10,000
Logs capacity 100,000
Algorithm Version ZK Face 7.0 & ZK Finger 10.0
2000mAh backup battery Optional
Communication TCP/IP,RS232/485
USB-HOST Two USB-Host
Wireless Wi-Fi Optional
Time attendance Standard functions ID Card(Optional), Automatic Status Switch, Self-Service Query,
Work Code, T9 input, 9 digit user ID, DLST
Access control interfaces for 3rd party electric lock, door sensor, exit button
Wiegand Signal Output
Optional functions Serial printer, Mifare card, Extendable Scheduled-bell, Short Massage, Web-server, GPRS
Power supply 12VDC 3A
Verification Speed ≤2 sec
Operating temp 0 °C- 45 °C
Operating Humidity 20%-80%
Dimension(W×H×D) 193.6×165×111 mm
Gross Weight 1.75 kg -
S922 TIME & ATTENDANCE TERMINAL
• Display 3.5-inch TFT Screen.
• Fingerprint Capacity 5, 000.
• Card Capacity 30,000 (ID Card).
• Transaction Capacity 200,000.
• Communication : Wi-Fi.
• Power Supply 12V 3A DC; Built-in Backup 7600 mAh Battery.
• Operating Temperature 0 ºC- 45 ºC.
• Operating Humidity 20%-80%.
-
ZK (IFACE 800)
Introduction:
With the latest ZKTeco’s platform and algorithm, iFace800 can hold up to 1, 200 face and 2,000 fingerprint templates and ensure accurate and fast authentication. Optional with RFID card, the customer has more choices to manage time attendance and access control. It also supports multiple authentication methods, including face, fingerprint, password, RFID card or their combinations, which make iFace800 more applicable. Multi-model communications consisted of RS232/485, TCP/IP, USB host and Wi-Fi/GPRS (optional) make data management extremely easy. Optional built-in 2000 mAh battery eliminates the trouble of power failure.
It fills your need of managing the time & attendance and access control conveniently.
Display
800 x 480 Pixel, LCD Capacitive Touch Screen
Verification Speed
≤1 sec (typical)
Fingerprint Sensor
ZK Optical
Supported Options
2000 mAh Backup Battery, Prox, Mifare
Camera
High Resolution Infrared Camera
Capacity
Face: 1,200(1:N)
Fingerprint: 2,000
ID Card: 10,000
Transaction: 100,000
Communications
Data: Ethernet, RS232 / 485, (Optional: Wi-Fi / GPRS)
Interface: USB Host, Wiegand Ports Output Only
Power
12V DC at 3A
Environment
Operating Temperature: 32º F – 113º F (0° C – 45° C)
Operating Humidity: 20% – 80%
Dimension
Widht: 7.6 in. (19.3 cm)
Hight: 5.5 in. (13.97 cm)
Depth: 3.75 in. (9.52 cm)
Net Weight: 1.4 lbs. (635 g) -
ZK (uFACE 800)
Introduction:
uFace800 facial multi-biometric time & attendance and access control terminal supports up to 1,200 face templates, 2,000 fingerprint templates and 10,000 cards (optional). With ZKTeco latest hardware platfrom and algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience. With advanced face algorithm and multi-biometric verification technology, the terminal’s security level of verification is significantly enhanced.
-
ZK 8500 RFID AND FP READER
•Fingerprint Optical Sensor.
•Operating Temperature 0° – 45°C.
•Enroll user fingerprint.
•Readily accessible for any finger.
•High speed USB interface.
•LED indicates the status of the device.
•Read ID card number.
•Read Mifare card number.
•High-performance optical fingerprint sensor.
-
ZK-U560-C
ZK-U560-C
-
ZKTECO MULTIBIOMETRIC TIME ATTENDANCE U160-C
Fingerprint Capacity
3000 templates
Transaction Capacity
100,000
Hardware Platform
ZEM510
Sensor
ZK Optical Sensor
Algorithm Version
ZK Finger v10.0
Communication
RS232/485, TCP/IP,USB-host, USB-client
Standard Functions
Webserver, Workcode, SMS, DLST, Scheduled-bell, Self-Service Query, Automatic Status Switch
Optional Functions
ID/Mifare/HID,RIS,printer,9 digit user ID
Display
3 inches TFT Screen
Power Supply
5V DC 2A
Operating Temperature
0 ℃- 45 ℃
Operating Humidity
20%-80%
Dimension
190X140X46 mm
Gross Weight
1.05 kg
