ZK FINGERPRINT F702-S
Just on touch! That’s all it takes for accessing control to ZKTeco’s F702-S biometric reader. It offers the flexibility to be installed standalone or with any third party panels that support 26-bit Wiegand. Fast, reliable performance and the affordability strengthen ZK reader’s competitive edge. Each reader has the capacity to store up to 2,200 fingerprint templates and 50,000 transactions. Enrolling users is fast and easy, Since most of our readers have a user-friendly keypad and display, enrolling users is fast and easy. All our readers are easily accessed. Together with a TCP/IP or a serial port, the readers can update and synchronize automatically.
-
ZK FINGERPRINT F18
Reliable, durable and highly accurate ZK fingerprint sensor with ver. 10 algorithm provides less than 1.5 second user recognition. Works without computer. Complete setup and programming can be done via keypads and embedded firmware. Graphical user interface on a 3.5 inch TFT display for rich user experience. Audio-Visual Indication for acceptance and rejection of valid/invalid fingerprints.
Relay outputs for electric lock and alarm. Inputs for door status sensor and exit switch. Supports multiple timezones and personnel groups for programming valid entry zones. The alarm will be triggered when the tamper switch is activated. Weigand output for connecting to access control panel and Ethernet port for fast and reliable communication with the computer.Can store up to 1500 templates and 30000 transactions. The data can be backed up to a USB flash drive and can also be transferred to another reader in the absence of computer connectivity. Internal Proximity Card or Mifare Card reader allows dual factor authentication for access control. -
ZK (TF1700 or F16)
Fingerprint Sensor ZK Optical Sensor Algorithm Version ZKFinger V10.0 Communication TCP/IP, RS485 Fingerprint Capacity 3,000 Fingerprints Card Capacity 30,000 Cards Log Capacity 100,000 transactions RF Card EM(standard)/Mifare(optional) Wiegand Signal Wiegand in & out Ingress Protection Rate IP65 Operating Voltage 12VDC 3A Operating Temperature 0℃~ 45℃ (32°F ~ 113°F) Size 62.5mm × 185mm × 41.5mm (W × H × D) -
TF1700 OUTDOOR
TF1700, one of the world’s smallest IP-based fingerprint terminals used for access control and time attendance features. With its IP65 rated rugged structure, TF1700 offers extra durability in all weather conditions including outdoor environments. It is specially designed for standalone applications such as house, office, shop, garage, factory and others.
-
SF101 Access control
Fingerprint Capacity 200 ID Card Capacity 100 Log Capacity 30,000 Sensor ZK Optical Sensor Case Metal case Relay contacts Door Lock, Alarm, Sensor, Exit button Proximity ID card LED Indicator Green / Red Operating Temperature 0°-45°C Operating Humidity 20%-80% Power 12V, DC 3A Communication Port RS232/485, USB-client Wiegand Output26bit Identification <= 2 seconds Verification < 1 second Dimensions 120 x 120 x 35 mm (L x W x D) Weight 0.9 kg -
SCR100 Access Control Reader
ID card Capacity 30,000 Transaction Capacity 50000 Communication TCP/IP, RS232/485, USB-Host Access Control Interface for 3rd party electric lock, door sensor, exit button, alarm, Door Bell Wiegand Signal Output & Input Standard Functions Anti-passback, Webserver, 9 digital numbers Optional Functions Mifare, HID Power Supply 12V DC Operating Temperature 0 ℃- 45 ℃ Operating Humidity 20%-80% Dimension (L*W*H) 153×95.5×35.5mm Gross Weight .8 kg -
SC103 Access Control Reader
ID card Capacity 30,000 Transaction Capacity 50,000 Communication TCP/IP, RS485, USB-Host Weigand Ports Input & Output Interfaces 3rd Party locks, door sensor, exit button Functions 50 time zones, 5 groups, 10 combinations Power Supply 12V DC 3A Optional Mifare、Print Function Dimensions 95 x 129 x 48mm -
PROXIMITY CARD ACCESS CONT
his new innovative and elegant looking RFID card reader and keypad is an access control reader that can be installed standalone with it’s relay output to any electric strike or magnetic lock or with any third party access panel that supports 64-bit Wiegand.
This card reader can be installed so it has a full time connection to a PC or network using ethernet or 232 serial or USB (Built in Serial and Ethernet ports and USB – all included! and can also be used completely stand alone so only a flash card is used to bring info to and from the reader.
This Prox reader conveniently reads standard proximity cards and fobs, HID* cards as a Special order – (please call for this). The user will benefit from their unparalleled performance using the state of the art proximity reader and embedded Linux platform.
-
Magnetic Lock
Introduction:
Features:
Model: AL-280(LED)
Unfold installation(middle)
Power-on to lock
No residual magnetism, no mechanical damage, single door
Lock status signal NO/NC output, LED display
90 degrees open for all kinds of doors with frame
Frameless doors or inswinging door doors can choose accessories
Inswing door accessories：AL-280PL and AL-280PZ
Frameless glass door accessories：AL-280PU -
MA300 Access Control
Fingerprint Capacity 1,500 templates Card Capacity 10,000 Transaction Capacity 100,000 Hardware Platform ZEM720 Sensor ZK Optical Sensor Algorithm Version ZKFinger VX10.0 Communication RS485,TCP/IP,USB-host Interfaces for Access Control 3rd party electric lock, door sensor, exit button, alarm Wiegand Signal Input & Output Standard Access Control Function Time Zone, Group, Anti-passback, external USB keypad Optional Functions IC Card, HID Display N/A Power Supply 12V DC Operating Temperature -10 °C- 60 °C Operating Humidity 10% -90% Protection Grade IP65 Dimension(W×H×D)mm 73×148×34.5 Gross Weight 1.15kg -
LH5000 Hotel Lock
The intelligent hotel lock system offers standalone solution to meet hotel’s demand on security and management, which features 13.56MHz Mifare card technology and hotel management software. The style and color of lock fit any type of hotel.
With the hotel management software, hotels can perform essential management tasks quickly and easily with minimal training.
The body of lock is made by zinc alloy which is strong enough to protect the system from any considerable outside impact. Lock is powered by four high-capacity alkaline AA batteries that can last up to 20,000 unlocking activities.
-
LH4000 Hotel Lock
The intelligent hotel lock system offers standalone solution to meet hotel’s demand on security and management, which features 13.56MHz Mifare card technology and hotel management software. The style and color of lock fit any type of hotel.
With the hotel management software, hotels can perform essential management tasks quickly and easily with minimal training.
The body of lock is made by zinc alloy which is strong enough to protect the system from any considerable outside impact. Lock is powered by four high-capacity alkaline AA batteries that can last up to 20,000 unlocking activities.
