SCD-2080R
Related Products
-
DS-2AF7268(N)-AW
Camera Image Sensor: | 1/4″ Interline Transfer CCD Effective Pixels: | PAL:976(H)×582(V)
NTSC:976(H)×494(V)Horizontal Resolution: | Color: 700 TVL
B/W: 750 TVLSignal System: | PAL/NTSC Min.illumination: | Color: 0.02Lux/(F1.6, AGC ON),0.0008Lux /(F1.6, AGC ON, IRE×256)
B/W: 0.002Lux/(F1.6, AGC ON),0.00008Lux /(F1.6, AGC ON, IRE×256)
0 Lux with IRWhite Balance: | Auto / Manual / ATW / Indoor / Outdoor AGC: | Auto/Manual S/N Ratio: | ≥ 50dB DNR: | 3D DNR BLC: | ON/OFF Shutter time: | PAL: 1/3 ~ 1/10,000s, NTSC: 1/4 ~ 1/10,000s Day&Night: | ICR Digital Zoom: | 16x Privacy Masking: | 8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen Focus Mode: | Auto / Semi-automatic / Manual Lens Focal Length: | 3.3-119mm, 36X Zoom Speed: | Approx.4.4s(Optical Wide-Tele) Angle of View: | 57.1°-1.7°(Wide-Tele) Aperture Range: | F1.4 – F4.2 Pan & Tilt Pan Range: | 360° endless Pan Speed: | Pan Manual Speed: 0.1° -160°/s,
Pan Preset Speed: 240°/sTilt Range: | -2°-90° (Auto Flip ) Tilt Speed: | Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 200°/sProportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples Number of Preset: | 256 Patrol: | 8 patrols, up to 32 presets per patrol Pattern: | 4 patterns, with the total recording time not less than 10 minutes Power-off Memory: | Support Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan PTZ Position Display: | ON/OFF Freeze Frame: | Support Password Protection: | Support Zone Scanning/Display: | Scanning within programmed zone, display zone title Camera Title: | Programmable title display Compass: | Support , the north can be set Scheduled Task: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan RS-485 communication diagnosis: | Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text Manchester code communication diagnosis: | Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text Smart-tracking: | Support Infrared IR Range: | 150m IR irradiation angle: | Adjustable by zoom Alarm Alarm Input: | 2 inputs(7 inputs optional) Alarm Output: | 2 relay outputs, alarm response actions option Input & Output Monitor Output: | 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC General Menu Language: | English / Chinese RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive Power Supply: | 24V AC Power Consumption: | Max. 52W Working Temperature /Humidity: | -30 ℃-65℃(-22℉-149℉)(outdoor dome)
90% or lessProtection Level: | IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protectionWiper: | Support Mounting: | Various mounting modes option Dimensions: | Φ245 ×399mm (Φ9.65” ×15.71” ) (Outdoor) Weight(approx.): | 5.5kg(12.13Ibs) Mount Option: | Long-arm wall mount: DS-1601ZJ; Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ -
DS-2CC52C2S-IT3P
Camera Image Sensor: | 1/3″ Progressive Scan CMOS Signal System: | PAL/NTSC Effective Pixels: | 1280(H)*720(V) Min. Illumination: | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR Shutter Time: | 1/100 s to 1/100,000 s Lens: | 3.6mm (2.8mm, 6mm, 8mm, 12mm, 16mm optional)
Angle of View: 78.8°(3.6mm), 103°(2.8mm), 51.2°(6mm), 37.6°(8mm), 24.6°(12mm), 18.8°(16mm)Lens Mount: | M12 Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360° Day& Night: | IR cut filter with auto switch Video Frame Rate: | 720p@25fps/720p@30fps HD Video Output: | SMPTE292M (HD-SDI) Synchronization: | Internal Synchronization General Operating Conditions: | -10 °C – 60 °C (14 °F – 140 °F)
Humidity 90% or less (non-condensing)Power Supply: | 12 V DC±10% Power Consumption: | Max. 6W Weather Proof: | IP66 IR Range: | Up to 40m Dimension: | Φ114.6 × 89.1mm(Φ4.5” × 3.5”) Weight: | 250 g (0.55lb) -
DS-2CC12A1P(N)-AVFIR3
Camera Image Sensor: | 1/3” SONY CCD Signal System: | PAL/NTSC Effective Pixels: | PAL: 976 (H) × 582 (V)
NTSC: 976 (H) × 494 (V)Min. Illumination: | 0.001Lux @ (F1.2,AGC ON) ,0 Lux with IR
0.0014Lux @ (F1.4,AGC ON),0 Lux with IRShutter Time: | 1/50(1/60)s to 1/100,000s Lens: | 2.8 – 12 mm @ F1.4
Angle of view: 80° – 27.2°Lens Mount: | φ14 Auto Iris: | DC Drive Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° Day& Night: | IR cut filter with auto switch Horizontal Resolution: | 700 TVL Wide Dynamic Range: | Digital Synchronization: | Internal/Power synchronization Video Output: | 1Vp-p Composite Output (75Ω/BNC);
Test Monitor OUT [1Vp-p Composite Output (75Ω/BNC),Device Line]S/N Ratio: | More than 62 dB Menu Camera ID: | On / Off (52 letters, position adjustable) D/N Mode: | Auto / Day / Night / EXT1 / EXT2 Auto White Balance: | ATW/Push/User1/User2/Anti CR/Manual/Push lock Private Mask: | On/Off, maximum 8 zones Motion Detection: | ON/Off BLC: | BLC/HLC/Off Eclipse: | On / off Language: | English/Chinese/ Korean/ Italian/ Russian/ Portuguese/ German/ French General Operating Conditions: | -10 °C – 60 °C (14 °F – 140 °F)
Humidity 90% or less (non-condensing)Power Supply: | 12 V DC ± 10%, 24 V AC ± 10% Power Consumption: | Max. 7.5 W
(Max. 8 W with IR cut filter on)Weather Proof: | IP66 IR Range: | Approx 30 to 40 meters Dimension: | 88 × 89.4 × 257.7mm(φ 3.46” x 3.52” x 10.15”) Weight: | 1350g (2.97 lbs) -
DS-2CE55C2P(N)-VFIR3
Camera Image Sensor: | 1/3” PICADIS Signal System: | PAL/NTSC Effective Pixels: | 1280 (H) × 960 (V) Min. Illumination: | 0.1Lux @ (F1.2,AGC ON),0 Lux with IR
0.14Lux @ (F1.4,AGC ON),0 Lux with IRShutter Time: | 1/25(1/30) s to 1/25,000(1/30,000) s Lens: | 2.8-12 mm @ F1.4
Angle of view: 80° – 27.2°Lens Mount: | φ14 Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360° Day& Night: | IR cut filter with auto switch Horizontal Resolution: | 720TVL Synchronization: | Internal Synchronization Video Output: | 1Vp-p Composite Output (75Ω/BNC) S/N Ratio: | More than 62 dB General Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)Power Supply: | 12 V DC±10% Power Consumption: | Max. 4 W(Max. 5 W with IR cut filter on) Weather Proof: | IP66 IR Range: | Approx 30 to 40 meters Dimension: | 134.2×123.9×88.1mm(5.28”×4.88”×3.47”) Weight: | 800g (1.76l lbs)
